【 Application Fields 】Power battery module, energy storage battery system, motor driver, energy storage power control system
 I Highlight Features

? Can comply with international standards for power battery testing: IEC, ISO, UL, GB/T, etc

? Equipped with battery discharge energy recovery and reuse function (Eff.)>90%,PF>0.95,I THD<5%)

? Equipped with automatic switching function for multiple voltage/current levels

High precision current/voltage measurement ± (0.05% rdg+0.05% F.S.) ± (0.02% rdg+0.02% F.S.)

Current ramp rate (0%~90%) 1ms（<300kW)10ms(300~600kW)

Dynamic (current/power) working condition simulation test: NEDC, FUDS, HPPC, etc

? Equipped with channel parallel connection function

Report data analysis function

? Support power-off reset testing function

Test the automatic protection function for abnormal situations

? Battery simulator function (optional)

High power detection equipment voltage range 60~1000V current range 0~1500A power range 0~600kW

? Customized integration function - Integrated temperature control box - BMS data reading and judgment - Multi channel voltage/temperature acquisition

Application of Motor Driver Testing for 48V Start Stop System of I Automobile
