I Highlight Features

?Three in one model for AC/DC withstand voltage and insulation resistance testing

?480 * 272 LCD display new generation ARM processor

?List display function, displaying multi-step results on one screen

?Keyboard lock function, automatically saves test conditions when turned off

?Short voltage rise time (fastest less than 0.2 seconds)

?Open short circuit detection function (OSC)

?Human body electric shock protection function (GFI)

?Automatic rapid discharge after the test is completed

?Current base reset function

?Support USB flash drive and internal file saving

?RS232 Handler interface configuration, suitable for automated testing and system configuration

The 2007 series programmable multifunctional withstand voltage tester has functions of AC withstand voltage testing, DC withstand voltage testing, insulation resistance testing, and arc detection. It has 3 sets of testing modes, can achieve programmable testing, and can be optionally equipped with RS485 interface.

Test items: AC withstand voltage/DC withstand voltage/green resistance.
