I Highlight Features

?AC/DC withstand voltage, insulation resistance test three in one safety standard model

?Programmable output voltage AC5KV, DC6KV

?Can output multiple signals of good/bad products for the product

?Programmable current MAX  AC10mA,DC5mA

?Handler signal output suitable for PLC software editing

?Insulation impedance 50G Ω

?Standard RS232, RS485

?Open/short circuit detection function OSC

?Panel locking function

?Human body protection function

?Programmable voltage output and limit value electrical flashover testing function

?4-8 channels in one device

?Can combine multiple output methods

?4-8 synchronous outputs and measurements

The Ns900 series can be applied to various electrical products, including time-consuming tests such as quality assurance sampling inspection and testing, production line testing, etc.

Featured feature: Air leakage current can reach OuA    And the leakage current of the instrument before testing can be attributed.
