【 Application Fields 】Chargers, power adapters, portable power banks, DC-DC converters, and other power sources.

 I Highlight Features

? Software settings for load parameters, real-time monitoring of output voltage, current, power and other parameters

CC and CV load optional modes

Under CC load mode, channels can be connected in series or parallel to meet various power products

? Product voltage and current can be freely selected for design

? Editable switch timing and multiple load transformation functions

? Multi functional adapter board is compatible with different products to facilitate interface docking between different products

? Aging warehouse body size and appearance with multiple structural options to solve different product aging and various on-site installations

? Internal resistance smoke detection alarm, over temperature alarm, leakage protection and other functions

? Support FCP, SCP, PD3.0+USBpps, PD2.0, QC2.0, QC3.0, QC4+, MTK PE2.0, D+D -, etc

Aging testing of various fast charging protocol chargers

Multiple voltage automatic switching functions (optional)

? Product area temperature monitoring function (optional)

? Energy saving and non energy saving multiple load modules can be optionally selected

Energy saving conversion efficiency of over 85%
