【 Application Fields 】Aging tests for mobile power banks, power banks, battery power supplies, and chargers.

 I Highlight Features

? Software settings for load parameters, real-time monitoring of output voltage, current, power and other parameters

CC and CV load optional modes

Real time monitoring of charging and discharging voltage, current, power, and other charging and discharging status of mobile power banks

Parallel connection of load channels in CC mode to meet product power expansion requirements

The charging and discharging aging of the product is achieved through bidirectional voltage regulation, achieving energy-saving and power-saving effects

? Editable switch timing and multiple load transformation functions

? Multi functional adapter board is compatible with different products to facilitate interface docking between different products

? Aging warehouse body size and appearance with multiple structural options to solve different product aging and various on-site installations

? Internal resistance smoke detection alarm, over temperature alarm, leakage protection and other functions

Supports bidirectional fast charging aging testing for various fast charging protocols such as FCP, SCP, PD3.0+USBpps, PD2.0, QC2.0, QC3.0, QC4+, MTK PE2.0, D+D -, etc

? Product area temperature monitoring function (optional)

? Energy saving and non energy saving multiple load modules are available (optional)

Energy saving conversion efficiency of over 85%
